G03ColorWriter Class Reference

GDML writer for the color attributes. More...

#include <G03ColorWriter.hh>

Inheritance diagram for G03ColorWriter:

Collaboration diagram for G03ColorWriter:

Public Member Functions
	G03ColorWriter ()
	~G03ColorWriter ()
void	AddExtension (xercesc::DOMElement *volumeElement, const G4LogicalVolume *const vol)
void	ExtensionWrite (xercesc::DOMElement *element)
void	ColorWrite (xercesc::DOMElement *volumeElement, const G4VisAttributes *const att)
G4bool	BookAttribute (const G4VisAttributes *const att)
Public Member Functions inherited from G4GDMLWriteStructure
	G4GDMLWriteStructure ()
virtual	~G4GDMLWriteStructure ()
virtual void	StructureWrite (xercesc::DOMElement *)
Public Member Functions inherited from G4GDMLWriteParamvol
virtual void	ParamvolWrite (xercesc::DOMElement *, const G4VPhysicalVolume *const)
virtual void	ParamvolAlgorithmWrite (xercesc::DOMElement *paramvolElement, const G4VPhysicalVolume *const paramvol)
Public Member Functions inherited from G4GDMLWriteSetup
virtual void	SetupWrite (xercesc::DOMElement *, const G4LogicalVolume *const)
Public Member Functions inherited from G4GDMLWriteSolids
virtual void	AddSolid (const G4VSolid *const)
virtual void	SolidsWrite (xercesc::DOMElement *)
Public Member Functions inherited from G4GDMLWriteMaterials
void	AddIsotope (const G4Isotope *const)
void	AddElement (const G4Element *const)
void	AddMaterial (const G4Material *const)
virtual void	MaterialsWrite (xercesc::DOMElement *)
Public Member Functions inherited from G4GDMLWriteDefine
G4ThreeVector	GetAngles (const G4RotationMatrix &)
void	ScaleWrite (xercesc::DOMElement *element, const G4String &name, const G4ThreeVector &scl)
void	RotationWrite (xercesc::DOMElement *element, const G4String &name, const G4ThreeVector &rot)
void	PositionWrite (xercesc::DOMElement *element, const G4String &name, const G4ThreeVector &pos)
void	FirstrotationWrite (xercesc::DOMElement *element, const G4String &name, const G4ThreeVector &rot)
void	FirstpositionWrite (xercesc::DOMElement *element, const G4String &name, const G4ThreeVector &pos)
void	AddPosition (const G4String &name, const G4ThreeVector &pos)
virtual void	DefineWrite (xercesc::DOMElement *)
Public Member Functions inherited from G4GDMLWrite
G4Transform3D	Write (const G4String &filename, const G4LogicalVolume *const topLog, const G4String &schemaPath, const G4int depth, G4bool storeReferences=true)
void	AddModule (const G4VPhysicalVolume *const topVol)
void	AddModule (const G4int depth)

Additional Inherited Members
Static Public Member Functions inherited from G4GDMLWrite
static void	SetAddPointerToName (G4bool)
Protected Member Functions inherited from G4GDMLWriteStructure
void	DivisionvolWrite (xercesc::DOMElement *, const G4PVDivision *const)
void	PhysvolWrite (xercesc::DOMElement *, const G4VPhysicalVolume *const topVol, const G4Transform3D &transform, const G4String &moduleName)
void	ReplicavolWrite (xercesc::DOMElement *, const G4VPhysicalVolume *const)
G4Transform3D	TraverseVolumeTree (const G4LogicalVolume *const topVol, const G4int depth)
void	SurfacesWrite ()
void	BorderSurfaceCache (const G4LogicalBorderSurface *const)
void	SkinSurfaceCache (const G4LogicalSkinSurface *const)
const G4LogicalBorderSurface *	GetBorderSurface (const G4VPhysicalVolume *const)
const G4LogicalSkinSurface *	GetSkinSurface (const G4LogicalVolume *const)
G4bool	FindOpticalSurface (const G4SurfaceProperty *)
Protected Attributes inherited from G4GDMLWriteStructure
xercesc::DOMElement *	structureElement
std::vector < xercesc::DOMElement * >	borderElementVec
std::vector < xercesc::DOMElement * >	skinElementVec
Static Protected Attributes inherited from G4GDMLWriteSolids
static const G4int	maxTransforms = 8

Detailed Description

GDML writer for the color attributes.

Definition at line 49 of file G03ColorWriter.hh.

Constructor & Destructor Documentation

G03ColorWriter::G03ColorWriter

(

)

Definition at line 40 of file G03ColorWriter.cc.

G03ColorWriter::~G03ColorWriter

(

)

Definition at line 47 of file G03ColorWriter.cc.

Member Function Documentation

void G03ColorWriter::AddExtension ( xercesc::DOMElement *  volumeElement, const G4LogicalVolume *const  vol  )

virtual

Reimplemented from G4GDMLWrite.

Definition at line 53 of file G03ColorWriter.cc.

Here is the call graph for this function:

G4bool G03ColorWriter::BookAttribute

(

const G4VisAttributes *const

att)

Definition at line 105 of file G03ColorWriter.cc.

Here is the caller graph for this function:

void G03ColorWriter::ColorWrite	(	xercesc::DOMElement *	volumeElement,
		const G4VisAttributes *const	att
	)

Definition at line 74 of file G03ColorWriter.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

void G03ColorWriter::ExtensionWrite ( xercesc::DOMElement *  element)

virtual

Reimplemented from G4GDMLWrite.

Definition at line 62 of file G03ColorWriter.cc.

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• D:/Geant4/geant4_9_6_p02/examples/extended/persistency/gdml/G03/include/G03ColorWriter.hh
• D:/Geant4/geant4_9_6_p02/examples/extended/persistency/gdml/G03/src/G03ColorWriter.cc
