G4FPYNormalFragmentDist Class Reference

#include <G4FPYNormalFragmentDist.hh>

Inheritance diagram for G4FPYNormalFragmentDist:
Collaboration diagram for G4FPYNormalFragmentDist:

Public Member Functions

 G4FPYNormalFragmentDist (G4int WhichIsotope, G4FFGEnumerations::MetaState WhichMetaState, G4FFGEnumerations::FissionCause WhichCause, G4FFGEnumerations::YieldType WhichYieldType, std::istringstream &dataFile)

 G4FPYNormalFragmentDist (G4int WhichIsotope, G4FFGEnumerations::MetaState WhichMetaState, G4FFGEnumerations::FissionCause WhichCause, G4FFGEnumerations::YieldType WhichYieldType, G4int Verbosity, std::istringstream &dataFile)

virtual ~G4FPYNormalFragmentDist (void)

- Public Member Functions inherited from G4FissionProductYieldDist
 G4FissionProductYieldDist (G4int WhichIsotope, G4FFGEnumerations::MetaState WhichMetaState, G4FFGEnumerations::FissionCause WhichCause, G4FFGEnumerations::YieldType WhichYieldType, std::istringstream &dataStream)

 G4FissionProductYieldDist (G4int WhichIsotope, G4FFGEnumerations::MetaState WhichMetaState, G4FFGEnumerations::FissionCause WhichCause, G4FFGEnumerations::YieldType WhichYieldType, G4int Verbosity, std::istringstream &dataStream)

G4DynamicParticleVectorG4GetFission (void)

G4IonsG4GetFissionProduct (void)

void G4SetAlphaProduction (G4double WhatAlphaProduction)

void G4SetEnergy (G4double WhatIncidentEnergy)

void G4SetTernaryProbability (G4double TernaryProbability)

void G4SetVerbosity (G4int WhatVerbosity)

virtual ~G4FissionProductYieldDist (void)


Protected Member Functions

void Initialize (void)

virtual G4IonsGetFissionProduct (void)

- Protected Member Functions inherited from G4FissionProductYieldDist
void CheckAlphaSanity (void)

G4IonsFindParticle (G4double RandomParticle)

G4IonsFindParticleExtrapolation (G4double RandomParticle, G4bool LowerEnergyGroupExists)

G4IonsFindParticleInterpolation (G4double RandomParticle, G4int LowerEnergyGroup)

G4IonsFindParticleBranchSearch (ProbabilityBranch *Branch, G4double RandomParticle, G4int EnergyGroup1, G4int EnergyGroup2)

virtual void GenerateAlphas (std::vector< G4ReactionProduct * > *Alphas)

virtual void GenerateNeutrons (std::vector< G4ReactionProduct * > *Neutrons)

G4IonsGetParticleDefinition (G4int Product, G4FFGEnumerations::MetaState MetaState)

G4String MakeDirectoryName (void)

G4String MakeFileName (G4int Isotope, G4FFGEnumerations::MetaState MetaState)

G4DynamicParticleMakeG4DynamicParticle (G4ReactionProduct *)

G4String MakeIsotopeName (G4int Isotope, G4FFGEnumerations::MetaState MetaState)

virtual void MakeTrees (void)

virtual void ReadProbabilities (void)

void Renormalize (ProbabilityBranch *Branch)

void SampleAlphaEnergies (std::vector< G4ReactionProduct * > *Alphas)

void SampleGammaEnergies (std::vector< G4ReactionProduct * > *Gammas)

void SampleNeutronEnergies (std::vector< G4ReactionProduct * > *Neutrons)

void SetNubar (void)

virtual void SortProbability (G4ENDFYieldDataContainer *YieldData)

void BurnTree (ProbabilityBranch *Branch)


Additional Inherited Members

- Protected Attributes inherited from G4FissionProductYieldDist
const G4int Isotope_

const G4FFGEnumerations::MetaState MetaState_

const
G4FFGEnumerations::FissionCause
Cause_

const G4FFGEnumerations::YieldType YieldType_

G4ENDFTapeReadENDFData_

G4IonsAlphaDefinition_

G4double AlphaProduction_

G4double TernaryProbability_

G4GammaGammaDefinition_

G4double IncidentEnergy_

G4double MeanGammaEnergy_

G4IonsNeutronDefinition_

G4double Nubar_

G4double NubarWidth_

G4int RemainingZ_

G4int RemainingA_

G4double RemainingEnergy_

G4int Verbosity_

ProbabilityTreeTrees_

G4IonsSmallestZ_

G4IonsSmallestA_

G4IonsLargestZ_

G4IonsLargestA_

G4int YieldEnergyGroups_

G4doubleYieldEnergies_

G4doubleMaintainNormalizedData_

G4doubleDataTotal_

G4int TreeCount_

G4int BranchCount_

G4IonTableIonTable_

G4ParticleHPNamesElementNames_

G4FPYSamplingOpsRandomEngine_


Detailed Description

G4FPYNormalFragmentDist is an inherited class of G4FissionProductYield that samples fission fragments from the entire data set.

Definition at line 45 of file G4FPYNormalFragmentDist.hh.

Constructor & Destructor Documentation

G4FPYNormalFragmentDist::G4FPYNormalFragmentDist ( G4int  WhichIsotope,
G4FFGEnumerations::MetaState  WhichMetaState,
G4FFGEnumerations::FissionCause  WhichCause,
G4FFGEnumerations::YieldType  WhichYieldType,
std::istringstream &  dataFile
)

Default constructor

  • Usage:
    • WhichIsotope: Isotope number of the element in ZZZAAA form
    • WhichMetaState: GROUND_STATE, META_1, or META_2
    • WhichCause: SPONTANEOUS or N_INDUCED
    • WhichYieldType: INDEPENDENT or CUMULATIVE
  • Notes:

Definition at line 43 of file G4FPYNormalFragmentDist.cc.

48 : G4FissionProductYieldDist( WhichIsotope,
49  WhichMetaState,
50  WhichCause,
51  WhichYieldType,
52  dataFile)
53 {
54  // Initialize the class
55  Initialize();
56 }
G4FissionProductYieldDist(G4int WhichIsotope, G4FFGEnumerations::MetaState WhichMetaState, G4FFGEnumerations::FissionCause WhichCause, G4FFGEnumerations::YieldType WhichYieldType, std::istringstream &dataStream)

Here is the call graph for this function:

G4FPYNormalFragmentDist::G4FPYNormalFragmentDist ( G4int  WhichIsotope,
G4FFGEnumerations::MetaState  WhichMetaState,
G4FFGEnumerations::FissionCause  WhichCause,
G4FFGEnumerations::YieldType  WhichYieldType,
G4int  Verbosity,
std::istringstream &  dataFile
)

Overloaded constructor

  • Usage:
    • WhichIsotope: Isotope number of the element in ZZZAAA form
    • WhichMetaState: GROUND_STATE, META_1, or META_2
    • WhichCause: SPONTANEOUS or N_INDUCED
    • WhichYieldType: INDEPENDENT or CUMULATIVE
    • Verbosity: Verbosity level
  • Notes:

Definition at line 59 of file G4FPYNormalFragmentDist.cc.

65 : G4FissionProductYieldDist( WhichIsotope,
66  WhichMetaState,
67  WhichCause,
68  WhichYieldType,
69  Verbosity,
70  dataFile)
71 {
72  // Initialize the class
73  Initialize();
74 }
G4FissionProductYieldDist(G4int WhichIsotope, G4FFGEnumerations::MetaState WhichMetaState, G4FFGEnumerations::FissionCause WhichCause, G4FFGEnumerations::YieldType WhichYieldType, std::istringstream &dataStream)

Here is the call graph for this function:

G4FPYNormalFragmentDist::~G4FPYNormalFragmentDist ( void  )
virtual

Default deconstructor. It is a virtual function since G4FPYNormalFragmentDist inherits from G4FissionProductYieldDist

Definition at line 125 of file G4FPYNormalFragmentDist.cc.

126 {
128
129  // Empty - all the data elements to be deconstructed are removed by
130  // ~G4FissionProductYieldDist()
131
133 }
#define G4FFG_FUNCTIONLEAVE__
#define G4FFG_FUNCTIONENTER__

Member Function Documentation

G4Ions * G4FPYNormalFragmentDist::GetFissionProduct ( void  )
protectedvirtual

Selects a fission product from the probability tree, limited by the number of nucleons available to the system.

Implements G4FissionProductYieldDist.

Definition at line 87 of file G4FPYNormalFragmentDist.cc.

88 {
90
91  G4Ions* Particle;
92
93  // Generate a (0, 1] random number and return the respective particle.
94  // The ENDF data tables lists 72172 as the largest fission fragment produced
95  // for any fission event. The maximum alpha production is 10 and the
96  // smallest fissile isotope is 90227. This means that if isotope 72172 were
97  // selected as the first daughter product, then at 10 alpha particles only
98  // 15 nucleons and -2 protons would remain for the second daughter product.
99  // Although the actual probability of this occurring is very small, or 0 in
100  // this case, a check should still be made to ensure that the second
101  // daughter product can be physically realized. This would prevent a
102  // situation such as this extreme example which results in a nucleus of 13
103  // neutrons and 2 anti-protons.
104  // This quick sanity check may become even more valid if the ENDF data
105  // tables are expanded in the future and include larger fission products.
106
107  G4int icounter=0;
108  G4int icounter_max=1024;
109  do
110  {
111  icounter++;
112  if ( icounter > icounter_max ) {
113  G4cout << "Loop-counter exceeded the threshold value at " << __LINE__ << "th line of " << __FILE__ << "." << G4endl;
114  break;
115  }
117  } while(Particle->GetAtomicMass() > RemainingA_ + 1
118  || Particle->GetAtomicNumber() > RemainingZ_ + 1);
119  // Loop checking, 11.05.2015, T. Koi
120
122  return Particle;
123 }
G4double G4SampleUniform(void)
G4Ions * FindParticle(G4double RandomParticle)
int G4int
Definition: G4Types.hh:78
G4GLOB_DLL std::ostream G4cout
Definition: G4Ions.hh:51
#define G4FFG_FUNCTIONLEAVE__
#define G4endl
Definition: G4ios.hh:61
#define G4FFG_FUNCTIONENTER__

Here is the call graph for this function:

void G4FPYNormalFragmentDist::Initialize ( void  )
protected

Initialize is a common function called by all constructors.

Definition at line 77 of file G4FPYNormalFragmentDist.cc.

78 {
80
81  // Nothing here yet
82
84 }
#define G4FFG_FUNCTIONLEAVE__
#define G4FFG_FUNCTIONENTER__

Here is the caller graph for this function:


The documentation for this class was generated from the following files:
