FCALTBEventAction Class Reference

#include <FCALTBEventAction.hh>

Inheritance diagram for FCALTBEventAction:

Collaboration diagram for FCALTBEventAction:

Public Member Functions
	FCALTBEventAction (FCALSteppingAction *)
virtual	~FCALTBEventAction ()
virtual void	BeginOfEventAction (const G4Event *)
virtual void	EndOfEventAction (const G4Event *)
void	SetDrawFlag (G4String val)
void	SetPrintModulo (G4int val)
Public Member Functions inherited from G4UserEventAction
	G4UserEventAction ()
virtual	~G4UserEventAction ()
virtual void	SetEventManager (G4EventManager *value)

Additional Inherited Members
Protected Attributes inherited from G4UserEventAction
G4EventManager *	fpEventManager

Detailed Description

Definition at line 45 of file FCALTBEventAction.hh.

Constructor & Destructor Documentation

FCALTBEventAction::FCALTBEventAction

(

FCALSteppingAction *

SA

)

Definition at line 60 of file FCALTBEventAction.cc.

  :drawFlag("all"),printModulo(10), StepAction(SA), eventMessenger(0)
{
  eventMessenger = new FCALTBEventActionMessenger(this);
}

FCALTBEventAction::~FCALTBEventAction ( )

virtual

Definition at line 68 of file FCALTBEventAction.cc.

{
  delete eventMessenger;
  eventMessenger = 0;
}

Member Function Documentation

void FCALTBEventAction::BeginOfEventAction ( const G4Event *  evt )

virtual

Reimplemented from G4UserEventAction.

Definition at line 76 of file FCALTBEventAction.cc.

{
  G4int evtNb = evt->GetEventID();
    if (evtNb%printModulo == 0)
    {
      G4cout << "\n---> Begin of event: " << evtNb+1 << G4endl;
//      HepRandom::showEngineStatus();
    }

  NTracksOutOfWorld = 0;
  NSecondaries = 0;

  StepAction->initialize(evtNb+1);
}

Here is the call graph for this function:

void FCALTBEventAction::EndOfEventAction ( const G4Event *  )

virtual

Reimplemented from G4UserEventAction.

Definition at line 93 of file FCALTBEventAction.cc.

{
  // Fill histograms
  G4AnalysisManager* man = G4AnalysisManager::Instance();

  NTracksOutOfWorld = StepAction->GetOutOfWorldTracks(0, 0);
  G4cout << "N Tracks out of world " << NTracksOutOfWorld << G4endl;

  man->FillH1(1,NTracksOutOfWorld);

  NSecondaries = StepAction->GetSecondaries(0,0);
  G4cout << "N Scondaries " << NSecondaries << G4endl;

  man->FillH1(2,NSecondaries);

  G4double EmEdep  = StepAction->GetEdepFCAL("FCALEm");
  G4double HadEdep = StepAction->GetEdepFCAL("FCALHad");


  man->FillH1(3,EmEdep/MeV);
  man->FillH1(4,HadEdep/MeV);


  G4cout<<"EmEdep is="<<EmEdep/MeV << " MeV " << G4endl;
  G4cout<<"HadEdep is="<<HadEdep << " MeV" << G4endl;

  G4cout << "Edep in FCAL1 FCAl2 : " << StepAction->GetEdepFCAL("FCALEm") << " ";
  G4cout << StepAction->GetEdepFCAL("FCALHad") << G4endl;
}

Here is the call graph for this function:

void FCALTBEventAction::SetDrawFlag ( G4String  val )

inline

Definition at line 55 of file FCALTBEventAction.hh.

{drawFlag = val;};

Here is the caller graph for this function:

void FCALTBEventAction::SetPrintModulo ( G4int  val )

inline

Definition at line 56 of file FCALTBEventAction.hh.

{printModulo = val;};

Here is the caller graph for this function:

---

The documentation for this class was generated from the following files:

• source/geant4.10.03.p02/examples/advanced/lAr_calorimeter/include/FCALTBEventAction.hh
• source/geant4.10.03.p02/examples/advanced/lAr_calorimeter/src/FCALTBEventAction.cc
