ExTGRCDetectorBuilder Class Reference

#include <ExTGRCDetectorBuilder.hh>

Inheritance diagram for ExTGRCDetectorBuilder:
Inheritance graph
[legend]
Collaboration diagram for ExTGRCDetectorBuilder:
Collaboration graph
[legend]

Public Member Functions

 ExTGRCDetectorBuilder ()

 ~ExTGRCDetectorBuilder ()

const G4tgrVolume * ReadDetector ()

virtual G4VPhysicalVolume * ConstructDetector (const G4tgrVolume *tgrVoltop)

- Public Member Functions inherited from G4tgbDetectorBuilder
 G4tgbDetectorBuilder ()

virtual ~G4tgbDetectorBuilder ()


Detailed Description

Detector builder class implementing cuts per region

Changes: creation May 2007

Author
: P. Arce

Definition at line 46 of file ExTGRCDetectorBuilder.hh.

Constructor & Destructor Documentation

ExTGRCDetectorBuilder::ExTGRCDetectorBuilder ( )

Definition at line 39 of file ExTGRCDetectorBuilder.cc.

40  : G4tgbDetectorBuilder(), fTlproc(0)
41 {
42 }
ExTGRCDetectorBuilder::~ExTGRCDetectorBuilder ( )

Definition at line 45 of file ExTGRCDetectorBuilder.cc.

46 {
47  if (fTlproc) { delete fTlproc; }
48 }

Member Function Documentation

G4VPhysicalVolume * ExTGRCDetectorBuilder::ConstructDetector ( const G4tgrVolume *  tgrVoltop)
virtual

Reimplemented from G4tgbDetectorBuilder.

Definition at line 68 of file ExTGRCDetectorBuilder.cc.

69 {
70  G4VPhysicalVolume* topPV =
71  G4tgbDetectorBuilder::ConstructDetector( tgrVoltop );
72
73  //--- Create regions
74  ExTGRCRegionCutsMgr::GetInstance()->BuildRegions();
75
76  //--- Set cuts to regions
77  ExTGRCRegionCutsMgr::GetInstance()->BuildProductionCuts();
78
79  return topPV;
80 }
G4tgbDetectorBuilder::ConstructDetector
virtual G4VPhysicalVolume * ConstructDetector(const G4tgrVolume *tgrVoltop)
Definition: G4tgbDetectorBuilder.cc:76
ExTGRCRegionCutsMgr::GetInstance
static ExTGRCRegionCutsMgr * GetInstance()
Definition: ExTGRCRegionCutsMgr.cc:45

Here is the call graph for this function:

Here is the caller graph for this function:

const G4tgrVolume * ExTGRCDetectorBuilder::ReadDetector ( )
virtual

Reimplemented from G4tgbDetectorBuilder.

Definition at line 51 of file ExTGRCDetectorBuilder.cc.

52 {
53  //------------------- construct geometry
54  fTlproc = new ExTGRCLineProcessor;
55  G4tgrFileReader* tfr = G4tgrFileReader::GetInstance();
56  tfr->SetLineProcessor( fTlproc );
57  tfr->ReadFiles();
58
59  //---------- find top G4tgrVolume
60  G4tgrVolumeMgr* tgrVolmgr = G4tgrVolumeMgr::GetInstance();
61  const G4tgrVolume* tgrVoltop = tgrVolmgr->GetTopVolume();
62
63  return tgrVoltop;
64 }
G4tgrFileReader::SetLineProcessor
void SetLineProcessor(G4tgrLineProcessor *lp)
Definition: G4tgrFileReader.hh:63
G4tgrFileReader::GetInstance
static G4tgrFileReader * GetInstance()
Definition: G4tgrFileReader.cc:72
G4tgrVolumeMgr::GetInstance
static G4tgrVolumeMgr * GetInstance()
Definition: G4tgrVolumeMgr.cc:63
G4tgrVolumeMgr::GetTopVolume
const G4tgrVolume * GetTopVolume()
Definition: G4tgrVolumeMgr.cc:292

Here is the call graph for this function:

Here is the caller graph for this function:

The documentation for this class was generated from the following files:
